Cyrix-Li-load 24/48V-230A
Cyrix-Li-load 24/48V-230A
IF PRODUCT IS OUT OF STOCK PLEASE CALL 01590 679418 OR EMAIL TO COMPLETE YOUR ORDER AND OBTAIN LATEST LEAD TIMES
Couldn't load pickup availability
The Cyrix-Li-load will disengage when its control input becomes free floating. If the battery voltage recovers after disconnection (which will happen when no other loads are connected to the battery), the output of the BMS will become high and the Cyrix will reengage after 30 seconds. After 3 attempts to reengage, the Cyrix will remain disengaged until battery voltage has increased to more than 13 V (resp. 26 V or 52 V) during at least 30 seconds (which is a sign that the battery is being recharged). Alternatively, a BatteryProtect can be used (advantage: very low power consumption).
Specification
| Protection Category |
IP54 |
|---|---|
| Manufacturer Part Number |
CYR020230450 |
| Weight (kg) |
0.27 |
| Dimensions |
H65 x W100 x D50mm |
| Brand |
Victron Energy |
| Control Cable Included (Length 1 m) |
Yes |
| Current Consumption When Open |
4 mA |
| Continuous current & Breaking capacity at 12V or 24V |
230A |
| LED Status Indication |
Yes |
| Voltage |
24/48 |
Click here for Cyrix-Li-Load Datasheet.
Disclaimer: Product images are for illustrative purposes only and may not be an exact representation of the products.
